Four Vessel Umbilical Cord

Parminder Kaur; Jaswir Singh

doi:https://10.7199/ped.oncall.2020.46

IMAGES IN CLINICAL PRACTICE

Four Vessel Umbilical Cord

Parminder Kaur¹, Jaswir Singh².

¹Department of Pediatrics, GMC Patiala, India,
²Prof. and Head of GMC Patiala, India.

ADDRESS FOR CORRESPONDENCE
Dr Parminder Kaur, House no 3079, Rajpura town, District Patiala, Punjab 140401.
Email: kaurparminder1991@yahoo.in

Show affiliations

Keywords
umbilical cord anomaly, 2 umbilical veins

A preterm girl was born at 34 weeks of gestation by vaginal delivery to primigravida mother aged 24 years. The baby weighed 2 kg at birth. The cause of preterm delivery was premature onset of labor pains. Baby cried immediately after birth. On routine general examination, it was found that umbilical cord had 4 blood vessels instead of routine 2 umbilical arteries and one umbilical vein (Figure 1). Other physical examination was normal. Ultrasound abdomen and echocardiography was normal. The hospital course was uneventful.

Which are the four vessel umbilical cord anomalies commonly seen?

Four vessel umbilical cord anomaly commonly seen are 2 umbilical arteries and 2 umbilical veins. This may be associated with multiple congenital malformations including congenital heart disease, genitourinary malformations, skeletal malformations, central nervous system malformations, cleft lip and fetal hydrops.¹ Usually single umbilical vein is present at birth and is derived from primitive left umbilical vein. Normally the right umbilical vein gets obliterated by 7 weeks of gestation.^2,3 Rarely persistence of caudal part of right umbilical vein can lead to presence of 2 umbilical veins. Incidence of persistence of right umbilical vein has been seen in 0.2-0.4% cases.⁴ Persistent right umbilical vein without any additional malformations has a good prognosis. In our patient, there were no other major congenital malformations. There have been few case reports on four vessel umbilical cord with no associated malformations.^5,6,7,8,9 Thus, routine examination of the umbilical cord postnatally for the number of blood vessels should be done and in case of multiple vessel cord, detailed examination and investigation to rule out any associated congenital malformations should be done.


Compliance with ethical standards
Funding: None
Conflict of Interest: None

References

Jeanty P. Persistent right umbilical vein: An ominous prenatal finding? Radiology.1990; 177:735-738 [CrossRef] [PubMed]
Heifitz SA. Single umbilical artery: a statistical analysis of 237 autopsy cases and review of the literature. Perspect Pediatr Pathol. 1984; 8:345-348
Theander G, Karlsson S. Persistent right umbilical vein. Acta Radiol. 1978; 19:268-274 [CrossRef] [PubMed]
Wolman I, Gull I, Fait G, Amster R, Kupferminc MJ, Lessing JB, Faffa AJ. Persistent right umbilical vein:Incidenceandsignificance.UltrasoundObstetGynecol. 2002; 19:562-564 [CrossRef] [PubMed]
Rodriguez MA. Four-vessel umbilical cord without congenital abnormalities. South Med J. 1984; 77:539 [CrossRef] [PubMed]
Murdoch D. Umbilical-cord doubling: Report of a case. Obstet Gynecol. 1966; 27:555-557 [CrossRef] [PubMed]
Schimmel M, Eidelman AI. Supernumerary umbilical vein resulting in a four-vessel umbilical cord. Am J Perinatol.1998; 15:299-301 [CrossRef] [PubMed]
Perez-Cosio C, Sheiner E, Abramowicz J. Four-vessel umbilical cord: not always a dire prognosis. J Ultrasound Med. 2008; 27:1389-1391 [CrossRef] [PubMed]
Singh N, Rao S, Sobti P, Khurana N. Multiple vessels in the umbilical cord: A report of four cases. Indian J Pathol Microbiol. 2012;55:597-8 [CrossRef] [PubMed]
